Metal SL (Selbstligierend)
79,00 €
zzgl. MwSt.
Hochwertiges und kleines selbstligierendes Edelstahlbracket mit stabilem Schliessmechanismus
Slot .022"
Roth oder MBT* Prescription
3,4,5 mit Hook
Stabiler Schiebe-Schließmechanismus
Packung: 1 Fall 5-5 (20 Brackets)
Hochwertiges und kleines selbstligierendes Bracket mit stabilem Schliessmechanismus
Hochwertiger Edelstahl
Slot .022"
Roth oder MBT* Prescription
3,4,5 mit Hook
Klein und grazil
Hoher Tragekomfort mit abgerundeten Kanten
Selbstligierende Technik
Zuverlässiger Schliessmechanismus
Anatomisch geformte Basis
Meshbasis für hohe Klebekraft
Packung: 1 Fall 5-5 (20 Brackets)
Roth Prescription:
Upper
| Tooth | 15 | 14 | 13 | 12 | 11 | 21 | 22 | 23 | 24 | 25 |
| in/out | 0.68 | 0.68 | 0.66 | 1.06 | 0.68 | 0..68 | 1.06 | 0.66 | 0.68 | 0.68 |
| torque | -7° | -7° | -2° | -8° | 12° | 12° | 8° | 2° | -7° | -7° |
| tip | 0° | 0° | 11° | 9° | 5° | 5° | 9° | 11° | 0° | 0° |
| width | 2.80 | 2.80 | 3.20 | 2.80 | 3.20 | 3.20 | 2.80 | 3.20 | 2.80 | 2.80 |
Lower
| Tooth | 45 | 44 | 43 | 42 | 41 | 31 | 32 | 33 | 44 | 55 |
| in/out | 0.68 | 0.72 | 0.68 | 1.06 | 1.06 | 1.06 | 1.06 | 0.68 | 0.72 | 0.68 |
| torque | -22° | -17° | -11° | -1° | -1° | -1° | -1° | -11° | -17° | -22° |
| tip | 0° | 0° | 5° | 0° | 0° | 0° | 0° | 5° | 0° | 0° |
| with | 2.80 | 2.80 | 2.80 | 2.50 | 2.50 | 2.50 | 2.50 | 2.80 | 2.80 | 2.80 |
MBT* Prescription:
Upper
| Tooth | 15 | 14 | 13 | 12 | 11 | 21 | 22 | 23 | 24 | 25 |
| in/out | 0.70 | 0.70 | 0.70 | 1.08 | 0.70 | 0.70 | 1.08 | 0.70 | 0.70 | 0.70 |
| torque | -7° | -7° | 0° | 10° | 17° | 17° | 10° | 0° | -7° | -7° |
| tip | 0° | 0° | 8° | 8° | 5° | 4° | 8° | 8° | 0° | 0° |
| width | 2.8 | 2.8 | 2.8 | 2.8 | 3.1 | 3.1 | 2.8 | 2.8 | 2.8 | 2.8 |
Lower
| Tooth | 45 | 44 | 43 | 42 | 41 | 31 | 32 | 33 | 44 | 55 |
| in/out | 0.70 | 0.70 | 0.70 | 0.90 | 0.90 | 0.90 | 0.90 | 0.70 | 0.70 | 0.70 |
| torque | -17° | -12° | 0° | -6° | -6° | -6° | -6° | 0° | -12° | -17° |
| tip | 2° | 2° | 3° | 0° | 0° | 0° | 0° | 3° | 2° | 2° |
| width | 2.80 | 2.80 | 2.80 | 2.20 | 2.20 | 2.20 | 2.20 | 2.80 | 2.80 | 2.80 |
*Our version of the Roth, and McLaughlin, Bennett, & Trevisi systems are not implied to be an exact version of any other system, nor do we claim any endorsement of their respective doctors.
